Airwave Cobra (PAST MODEL)Airwave Cobra (PAST MODEL)Airwave Cobra (PAST MODEL)Airwave Cobra (PAST MODEL)Airwave Cobra (PAST MODEL)Airwave Cobra (PAST MODEL)
Past Model
Airwave Cobra (PAST MODEL)
Airwave Cobra (PAST MODEL)
Airwave Cobra (PAST MODEL)
Airwave Cobra (PAST MODEL)
Airwave Cobra (PAST MODEL)
Airwave Cobra (PAST MODEL)

Airwave Cobra (PAST MODEL)

SKU : AIRWV-COBRA-M-CL


A top performing sports wing with attitude

The Cobra has exceptionally high performance for its class and is as close to being a true three-line glider as possible. It supersedes the top selling Mustang2.
Technology fed down from the Magic5 has given the Cobra a very low sink rate and an outstanding glide. This significant leap in performance comes from two important areas of development.
Firstly the Cobra has a new hybrid line configuration. For most of the span there are only three lines, except high up in the centre of the wing where short D lines branch off to give greater stability. The result is a 15% reduction line from the Mustang2, with the total length dropping 60m, from 385m to just 326m. Secondly a new airfoil design and internal airflow management has helped us increase the aspect ratio from 5.7 on the Mustang2 to 5.95.
Our in-house design software estimated these advances would bring about an increase in glide of around 0.85. But software estimations are notoriously fickle, and real glide tests proved the figure wrong. The improvement in glide has been a whole point in glide! Leaps in performance often come at the price of security. However, having dedicated ourselves to the pursuit of our trademark Airwave easy handling, we are confident that you'll find the Cobra to be an easy and stress-free wing to fly and as accessible to as wide a range of pilots as it's predecessor.

Product Details

A top performing sports wing with attitude

The Cobra has exceptionally high performance for its class and is as close to being a true three-line glider as possible. It supersedes the top selling Mustang2.
Technology fed down from the Magic5 has given the Cobra a very low sink rate and an outstanding glide. This significant leap in performance comes from two important areas of development.
Firstly the Cobra has a new hybrid line configuration. For most of the span there are only three lines, except high up in the centre of the wing where short D lines branch off to give greater stability. The result is a 15% reduction line from the Mustang2, with the total length dropping 60m, from 385m to just 326m. Secondly a new airfoil design and internal airflow management has helped us increase the aspect ratio from 5.7 on the Mustang2 to 5.95.
Our in-house design software estimated these advances would bring about an increase in glide of around 0.85. But software estimations are notoriously fickle, and real glide tests proved the figure wrong. The improvement in glide has been a whole point in glide! Leaps in performance often come at the price of security. However, having dedicated ourselves to the pursuit of our trademark Airwave easy handling, we are confident that you'll find the Cobra to be an easy and stress-free wing to fly and as accessible to as wide a range of pilots as it's predecessor.

Technical Info

Size / Type

S

M

L

XL


Linear scaling factor

0,96

1

1,04

1,08


Projected area (Sq m)

20,31

22,04

23,70

25,71


Flat area (Sq m)

23,89

25,92

28,04

30,23


Weight excl bag (kg)

5,8

6,2

6,7

7,23


Total line length (m)

313

326

353

380,25


Height (m)

7,38

8,01

8,33

8,66


Number of main lines

3/4/3

3/4/3

3/4/3

3/4/3


Cells

57

57

57

57


Flat aspect ratio

5,95

5,95

5,95

5,95


Projected aspect ratio

4,37

4,37

4,37

4,37


Root cord (m)

2,48

2,58

2,68

2,78


Flat span (m)

11,926

12,423

12,920

13,417


Weight range (kg (PTV))

65 - 90

80 - 105

100 - 120

115-140


Trim speed (Km/h)

39

39

39

39


Top speed (Km/h)

52

52

52

52


Min sink (m/sec)

1

1

1

1


Best glide

9

9

9

9


Certification

EN:C LTF 2

EN:C LTF 2

EN:C LTF 2

uncertified

Colours

Downloads

Manual

Layout plan


EN-Test report

Cobralinelenghts

More Info

  • EN C
  • LTF 2
