Ask about Niviuk Arrow P M 00M01699
Product Details
Technical data
| Size | S | M | L |
|---|---|---|---|
| Pilot height (cm) | 160 - 172 | 170 - 182 | 178 - 195 |
| Weight of harness - inflatable protection (kg) * | 1.61 * | 1.63 * | 1.78 * |
| Weight of harness - foam protection (kg) * | 1.69 * | 1.71 * | 1.87 * |
| Back length (cm) | 60 | 60 | 64 |
| Seat base width (cm) | 33 | 33 | 35 |
| Seat base length (cm) | 49 | 50 | 55 |
| Cockpit top pocket (L) | 0.05 | 0.05 | 0.05 |
| Cockpit bottom pocket (L) | 0.025 | 0.025 | 0.025 |
| Under seat pocket volume (L) | 4 | 4 | 5 |
| Back pocket volume (L) | 17 | 17 | 20 |
| Nose pocket volume (L) | 6 | 6 | 7 |
| Rescue compartment volume (L) | 4 - 6 | 4 - 6 | 4 - 6 |
| Carabiner distance (cm) | 41 - 43 | 41 - 43 | 43 - 45 |
| MAX. Load (kg) | 120 | ||
| Certification | EN | ||
| Protection certification | EN/LTF | ||
* Carabiners and speedbar included in weight
The total weight of the harness may differ ±5% due to variations in the weight of the fabric supplied by the manufacturers.
Sizing guide chart
Package
- Harness
- Aerodynamic tail
- Carabiners
- Pod (speedbag)
- Reserve handle (aka "Rescue handle")
- Foam protection*
- Speed bar
- Cockpit
* Niviuk developed an inflatable protector that you can order as an optional extra.
Optional extras (Related Products)
Note: The Arrow P speedbag sizes are not interchangeable between Arrow P harness sizes. Each size of Arrow P speedbag corresponds to its size of harness e.g. the size M Arrow P harness only accepts the size M Arrow P speedbag.
Flybubble Note: Ultra-light gear must be handled with care to extend its lifespan. Mechanical stresses and improper handling can cause faster wear and tear compared to standard-weight gear. Designed for hike and fly activities, ultra-light gear prioritizes weight savings over durability and other factors. To avoid damage, refrain from extreme activities or excessive ground handling. Gentle treatment is crucial for longevity and safe operation.
ARROW P: BEYOND YOUR LIMITS
- Ultra-light harness with a fairing and pod
- 3D-modelled seat: comfort and safety
- Maximum stability due to the applied triangulation system
Target
Cross-country and Hike & Fly
The Arrow P has been designed for the most demanding hike & fly pilots. An ergonomic and compact harness perfectly suited for XC flights as well as vol biv adventures in the mountains. Travel long distances on foot or in the air with a lightweight, stable and comfortable harness.
Features
Protection system
Niviuk has worked to develop a very compact foam protection that offers the best compromise between lightness and impacts absorption. At 14 cm thick and weighing 320 g, it is made of three different layers of low density foam. This protection helps to provide a very comfortable seat without the need for a seat plate on the harness.
Additionally, you can order Apair inflatable protection. It is ideal for pilots looking for small volume, safety and lightness on their hike & fly adventures. EN and LTF certified, this ultralight protector weights only 240 g and distinguishes itself by its efficiency and practicality. It is delivered with the Infbag cover, which facilitates inflation and also serves as a compression bag for packing and transporting the harness.
Excellent stability in flight
In order to ensure total comfort, Niviuk's R&D team has worked hard on the chassis to guarantee a high level of flight stability. Thanks to the triangulation system applied, the Arrow P is a stable harness that better absorbs excess movements transmitted to the pilot, making it more efficient, especially in accelerated flight.
Integrated parachute
Niviuk has focused on safety and ease of use by integrating the parachute container on the right side of the harness. This makes it more user-friendly, especially in everyday use, and much more comfortable.
Aerodynamic performance
The fairing optimises its aerodynamic shape, reducing drag. This makes it more balanced in yaw, resulting in a more stable, high-performing and precise harness
.
The perfect fit
On the Arrow P, the chest strap is adjustable and the shoulder straps can be adjusted to your preference with a simple loop on the maillon. It also has adjustable back and lumbar straps to adapt the angle and the harness to the pilot’s body shape. The pod can be removed with a zip for easy replacement.
Arrow P, a harness for all pilots
The knowledge gained from the development of the Arrow and Drifter 2 harnesses has been applied to design an extremely light pod harness that offers high performance and aerodynamics. The Arrow P is very compact and easy to pack.
P Series harness with fairing
Thanks to technical know-how and optimisation of materials, Niviuk has been able to develop the Arrow P: one of the lightest pod harnesses on the market, without sacrificing the features and performance of the standard models. It has been extensively researched in terms of structure, materials, durability and strength. Big teamwork to offer the best quality in all aspects.
Super-light
An ultra-light harness, from 1.61 kg, the perfect partner for hike & fly enthusiasts. Like all Niviuk's P Series products, light materials have been used for its development. The pod is made of D70, a lightweight fabric with good tear resistance, and the rest is made of Lycra light for added stretch. The inflatable fairing is made from Skytex 27 g inside and Skytex 32 g outside.
100% comfortable
Introducing a harness with exceptional comfort, thanks to the 3D-modelled seat. Ergonomic structure adapted to your needs. The triangulation system used optimises stability, which translates into comfort and efficiency in accelerated flight.
Arrow P VS Arrow P Race
* Carabiners and speedbar included in weight
Materials
- TAIL: Skytex 32g
- Coverleg: D70
- Coverleg elastic front part: Light lycra
- Body: D70
- Main webbings: Liros dyneema 4mm
Downloads
