Ask about Advance PIBI
Product Details
Technical Data
| PIBI | 37 |
|---|---|
| Recommended takeoff weight (kg) | 100 - 180 |
| Flat surface (m2) | 37.2 |
| Projected surface (m2) | 31.8 |
| Glider weight (kg) | 4.8 |
| Span (m) | 14.2 |
| Projected span (m) | 11.4 |
| Aspect ratio | 5.4 |
| Projected aspect ratio | 4.1 |
| Number of cells | 53 |
| Number of risers | 3+1 |
| Certification | EN / LTF B |
| Trimmers | YES / 8cm |
Colours
Standard colours: White (Orange-White-Pacific)
Package
- Wing
-
COMPRESSBAG
- Light Spreaders
Optional extras
PI BI - Family Affair
Special: It’s not just the weight and volume; even the handling and agility of the light tandem remind one of a solo wing. The PI BI has three risers and trims, like the BIBETA 6, and is fitted with robust Edelrid Aramid lines. PI BI – dynamic flying fun for two.
Despite its low weight and very small packed volume, similar to a solo wing, the PI BI is a fully-capable tandem wing with effective trims which give it a large speed range. This is made possible by a very compact build method and minimalist inner life. As well as the tandem certification the PI BI is also approved for solo flying.
Features
Light Spreaders
The PI BI is delivered with a pair of light spreaders with reserve connection lines (180 gm) and two FORAS carabiners (102 gm) as well as a COMPRESSBAG Light (150 gm).
Light Risers
The PI BI three level risers are weight optimised and weigh only 345 gm. They connect via Softlinks and are fitted with Low Friction brake rings.
Suitable harnesses
The BI PRO 3 pilot harness goes especially well with the EASINESS 2 reversible harness for the passenger. The PI BI was tested and set up with it.
Optional backpacks
Depending on how light and small a complete package is desired, the PI BI can be combined with various rucksack sizes.
ADVANCE recommend the following setups:
- COMFORTPACK 3, 115 ltr: PI BI + BI PRO 3 incl. protector + standard passenger harness
- COMFORTPACK 3, 100 ltr or LIGHTPACK 2, 90 ltr: PI BI + BI PRO 3 without protector + standard passenger harness
- EASINESS 2 rucksack* and PIPACK 2*: PI BI + BI PRO 3 without protector + EASINESS 2 for passenger
- PIPACK 2: PI BI + STRAPLESS BI + STRAPLESS for passenger
*PI BI in EASINESS 2, BI PRO 3 in PIPACK 2
Materials
| Leading edge | Skytex 32 universal |
|---|---|
| Upper surface | Skytex 27 classic II |
| Lower surface | Skytex 27 classic II |
| Designstripe | Skytex 32 universal |
| Profiles | Skytex 32 hard finish |
| Unsuspended profiles | Skytex 27 hard finish |
| Main lines | A-8000U-360, -280, -230, -190 |
| Gallery lines | A-8000U-190, -130, -090, -070, -050 |
| Brake lines | A-8000U-190, -130, -090 |
| Steering lines | A-7850-240 |
| Risers | Polyester/Technora 13mm, 850daN |
| Softlinks | Softlink DC 500 |
