Flytec 6010 (PAST MODEL)

The Flytec 6010 Alti-Vario flight instrument has all of the excellent features of the Flytec 6005 plus a barograph with up to 130 hours recording time which records altitude, altitude and speed, or altitude and temperature with a user-adjustable recording interval (1, 5, or 15 seconds).

All the features of the Flytec 6005...

• 3 altimeters.
• Digital and analog variometer.
• Smart-filter technology.
• User customizable audio.
• 5 full-time data fields.
• Always-on realtime clock.
• Louder audio with 6 settings.
• Ambient temperature.
• Battery life over 250 hours (2xAA).
• Airspeed sensor ready.
• Superb ergonomics and styling.
• Very compact and light.

... Plus:

• Barograph with up to 130 hours record time.
• Recording interval: 1, 5, 15 seconds.
• Recording of altitude, altitude and speed, or altitude and temperature.
• USB port and FlyChart compatible.

Function Overview

Here below is an overview of the functions that the Flytec 6010 has...

Altimeter

• Altimeter 1 - MSL up to 37,000 ft (11,500 m).
• Altimeter 2 - Absolute or relative (ft or m).
• Altimeter 3 - Reference altitude with one button zeroing at any time.
• QNH: Set altitude with barometric pressure.
• MSL altimeter user correctable (no need to to send in for calibration).

Variometer

• Analog display - patented twin pass scale up to ±2000 ft/mn (10 m/s).
• Digital display - up to 19,200 ft/min (96 m/sec) in 10 ft/mn increments.
• Averager - users selectable between 1-30 seconds
• Sink alarm - user slectable threshold (can be easily disabled).

Extensive Audio Control

• 6 loudness settings.
• Adjustable vario threshold.
• Adjustable pitch.
• Adjustable dampening.
• Smart-Filter technology minimizes false lift indication.
• ASI - audio scale indication.

Speed

• Digital speed display - 3 user selectable ranges 0-30, 0-60, or 0-120 mph with optional HG or PG sensor.
• Speed display in mph, kph or knots.
• Stall alarm - User selectable threshold (requires optional sensor).
• Airspeed correction: ±50%.

Temperature

• Current ambient temperature in Fahrenheit or Celsius w/ 1 resolution.
• Temperature correction ± 14.2 F.

Time

• Real-time clock - Always-on time and date.
• Flight timer - keeps track of flight duration.
• Stopwatch - may be started, stopped and reset during flight.

Flight Log

• Automatically records 50 most recent flights.
• Records peak values of: altitude 1 and 2, analog lift and sink, digital lift and sink, flight duration and date of flight.
• Recorded flights and values may be displayed at any time.
• Flight memory data maintained if batteries are removed.

Barograph

• Automatically recording - no need to turn on barograph!
• Up to 130 hours of recording.
• Recorded intervals 1, 5 & 15 sec.
• Record: altitude, altitude and speed, or altitude and temperature.

Physical Properties

• Extremely easy to read display.
• 5 full-time digital displays, analog display and instrument status display (mode, battery, sink alarm, loudness).
• Intuitive function button allocation.
• Compact, light, rugged, ergonomic and aerodynamic housing.
• Size: 5-3/8" x 2-7/8" x 13/16" (138 x 74 x 23 mm).
• Weight: 6.4 oz.(182 g) including batteries without clamp.

Power Supply

• Battery life over 250 hours on 2 AA (included).
• 10 years in standby mode.
• Continual display of battery status.

What's Included

• Protective carry bag
• Batteries
• USB cable
• Manual
• FlyChart license (self generated on first connection)
• Warranty : 2 years
