Ask about Ozone Arc
Product Details
Technical data
| Size | 6.5 | 8 | 10 | 12 | 14 |
|---|---|---|---|---|---|
| IWR¹ (kg) | 50-95 | 50-95 | 50-97 | 50-97 | 50-97 |
| Flat Area (m2) | 6.5 | 8 | 10 | 12 | 14 |
| Projected area (m2) | 5.8 | 7.1 | 8.9 | 10.6 | 12.4 |
| Flat Aspect Ratio | 3.5 | 3.5 | 3.5 | 3.5 | 3.5 |
| Projected Aspect Ratio | 2.8 | 2.8 | 2.8 | 2.8 | 2.8 |
| Number of cells | 27 | 27 | 27 | 27 | 27 |
| Projected Span (m) | 4.01 | 4.45 | 4.98 | 5.45 | 5.89 |
| Flat Span (m) | 4.77 | 5.29 | 5.92 | 6.48 | 7.00 |
| Root Chord (m) | 1.64 | 1.82 | 2.03 | 2.23 | 2.41 |
| Glider Weight (kg)* | 1.75 | 1.93 | 2.16 | 2.45 | 2.70 |
| Load test | EN-926 | EN-926 | EN-926 | EN-926 | EN-926 |
* Weights may vary up to 50gm per size due to slight variations in the manufacturing of the fabric used.
¹ IWR: In-flight Weight Range in kilograms (kg).
Colours
Standard colours: LKW, RKA, CHK
Custom colours: Choose your colours and email us the colour reference with your order. Include a screenshot if you can. Full payment required upfront to confirm your order after which it cannot be cancelled.
Package
Your Ozone wing is delivered standard with the following accessories:
- Speedwing Stuff Bag*
- Ozone Certificate Of Origin
- Riser Bag (containing repair fabric and stickers)
- Bottle Opener, Keyring
- Inner Bag
- Glider Strap
*The Speedwing Stuff Bag is also known as the Speed Wing Stuff Sack, Speed Wing Sack and Speed Stuff Bag. It's a small fast packing bag designed for speed wings and small mini wings. This wing comes as standard with the bag size to match the wing included; it's not possible to choose the bag size.
Related Products (optional extras)
You may choose to add something to your order, such as:
- Ozone Concerto Light folding bag
- Glider Backpack
- Ozone Easy Bag (quick stuff sack)
- OZONE Clothing and Accessories
Ozone ordering information
Ozone make their wings to order and give an estimated lead time in working days on their website, for example: "The current production time is approximately 43 days from order to shipping". Add 1-3 weeks for shipping, and allow for unexpected delays. If their website shows "Lead time is currently unavailable." then this means they are unable to give an estimated lead time. Contact us for more information and to place your order.
Arc: Steep & Stable Big Mountain Wing
Inflation & Launch
The Arc launches rapidly. It has the predictable and dependable launch behavior that is critical for dropping into steep big mountain lines. It inflates quickly even from a compressed layout.
On Snow
The Arc’s brake range is very long, longer than almost any speed wing we have flown. Its deep brake behavior allows you to make powerful inputs without stalling or over-controlling the wing. This same characteristic makes rapid disconnects and re-landings easy on steep lines, and enables freestyle maneuvers such as riding switch and taking grabs accessible earlier in a pilot’s skill-progression.
Trim Range & Glide
The Arc has the longest trim-range of any of Ozone Speedwing. With trims fully released, its glide is very steep. Because the trim range is so extensive, it ships with the final 3cm of trim-range stitched closed. It is up to the pilot to cut the stitching to access the full trim range.With trims pulled in, the Arc’s max glide is impressive for a ski-specific wing - it is comparable to the Dragonfly series.
Foot-launch Flights
Although designed with the Speedrider in mind, the Arc’s significant trims-in launch capability make it a fun, safe, and stable wing for foot-launched speed flying. Many pilots prefer the feel of both the lighter weight fabric and risers, as well as the shorter line-lengths for intermediate-to-advanced level classic speedflying.
Materials & Design
A lighter system means lower sail inertia which means better behavior when navigating technical terrain at low speed with the wing unloaded due to the pilot riding on the surface. Light risers and fabric help the canopy to remain overhead at low airspeeds. Sheathed lines provide durability and a new neoprene brake-handle design is optimized for gloves, with classic snaps rather than magnets.
The Pilot
The Arc serves a broad range of beginner to advanced speedriding pilots who want a wing capable of true speed riding. It is recommended for those with prior piloting paragliding or speed riding experience. It is available in three sizes: 12m / 10m / 8m / 6.5m
The Arc 6.5m represents the pinnacle of speed, steepness and stability - targeted specifically at advanced Speedriders, as well as lighter-weight pilots, eager to maintain contact with the snow.
Features
- Optimized for big-mountain riding
- Highly stable at low angles of attack and steep lines
- Short line length, long trim range
- Rapid, reliable inflations on launch
- Capable and comfortable in foot-launch applications
- Light but durable design, with sheathed lines
Materials
- Top Surface Cloth: Dominico N20D
- Bottom Surface Cloth: Dominico N20D
- Rib cloth: Dominico 30D (hard)
- Upper lines: Liros DSL 70
- Mid lines: Liros DSL140
- Lower Lines: Edelrid 6843-240/200
