Ask about Ozone Zeolite 2
Product Details
Technical data
| SIZES | XS | S | MS | ML |
|---|---|---|---|---|
| In-flight Weight Range (kg) | 60-75 | 65-85 | 80-95 | 90-105 |
| Number of cells | 71 | 71 | 71 | 71 |
| Projected area (m2) | 15.9 | 17.2 | 18.5 | 19.8 |
| Flat Area (m^2) | 18.9 | 20.4 | 22 | 23.5 |
| Projected Span (m) | 8.9 | 9.3 | 9.6 | 9.9 |
| Flat Span (m) | 11.3 | 11.8 | 12.2 | 12.6 |
| Projected Aspect Ratio | 5 | 5 | 5 | 5 |
| Flat Aspect Ratio | 6.8 | 6.8 | 6.8 | 6.8 |
| Root Chord (m) | 2.09 | 2.17 | 2.26 | 2.33 |
| Glider Weight (kg)* | 2.72 | 2.88 | 3.03 | 3.16 |
| EN | D | D | D | D |
* Weights may vary up to 50gm per size due to slight variations in the manufacturing of the fabric used.
Colours
Standard colours: WRK/W = white red black / white,, HRK/H = lime red black / lime.
Custom colours: Choose your colours and email us the colour reference with your order. Include a screenshot if you can. Full payment required upfront to confirm your order after which it cannot be cancelled.
Package
- Special Folding Pillow
- Concerto Light Folding Bag
- Key Ring
- Bottle Opener
- Certificate of Authenticity
- Two Sheets of White Sticky Cloth
- Riser Bag
Optional extras
- Glider Backpack
- Easy Bag (quick stuff sack)
- OZONE Clothing and Accessories
Ozone production times
Ozone wings are made to order. Ozone gives their current approximate production time on their website in working days, for example: "The current production time is approximately 28 days from order to shipping". Add 1-3 weeks for shipping, and allow for unexpected delays. Some may claim shorter delivery times however we're unsure how they can supply faster than the manufacturer themselves can produce and ship! ;-)
Zeolite 2: LIGHT PERFORMANCE / COMPETITION - EN D
- Developed from 2023 Red Bull X-Alps competition wing
- Uncompromising ultra-light high performance
- Same weight as predecessor, with higher performance
- Improved agility and handling, with high solidity in active air
The Design
The profile has evolved to include the latest progress we've made in the areas of speed and handling. Principally, the benefits have come from a new cell opening position.
The aspect ratio is slightly increased, but still moderate for the category and has proved to be comfortable in strong alpine conditions. The cell count is increased by 7, which improves the sail cohesion in turbulent air, improves the handling, and increases performance whilst maintaining the same weight as the original Zeolite.
In Flight
Passive safety and collapse behavior has been improved via better chordwise line support at the rear of the wing. Despite the improved support, total line drag is less than its predecessor. A new spanwise architecture is made entirely of 3-cell bridges, similar to the Photon. This allows the best diagonal panel ratio for the amount of line attachments, which maintains light weight while increasing efficiency.
Materials
- Top Surface Cloth: Dominico 10D
- Bottom Surface Cloth: Dominico 10D
- Rib cloth: Porcher 70000 E29 (hard)
- Upper lines: Edelrid 8001 serie
- Mid lines: Edelrid 8001 serie
- Lower Lines: Edelrid 8001 serie
