Nova Mentor 3 Light (PAST MODEL)

SKU : NOVA-MENTOR3L-XXS-GN

The basic design of the Mentor 3 Light and Mentor 3 is the same. A few weight reducing features make the difference: The Light version weighs over 1.5kg less. The flight characteristics remain quite the same, however the reduced canopy weight slightly improves the launch behaviour and the reaction to collapses. Of course it's not quite as durable.

Product Details

We reduced the weight of the Mentor 3 Light with the following measures:

lighter cloth (32g/sqm) on the rear top sail
lighter cloth (27g/sqm) on the bottom sail.
lighter risers.
more cut outs on some inner parts, like on the profile ribs
some more slightly adapted design details

For further information about design, performance and flight characteristics see the Nova Mentor 3.

Technical Specifications

Size		XXS	XS	S	M	L
Zoom factor		0.88	0.93	0.97	1.01	1.05
No of cells		51	51	51	51	51
Projected wingspan	m	8.46	8.9	9.32	9.72	10.11
Projected surface area	m²	18.36	20.33	22.3	24.26	26.21
Projected aspect ratio		3.9	3.9	3.9	3.9	3.9
Flat wingspan	m	10.86	11.42	11.96	12.48	12.97
Flat surface area	m²	21.68	24	26.33	28.65	30.96
Flat aspect ratio		5.43	5.43	5.43	5.43	5.43
Line diameter	mm	0.6 / 0.7 / 0.8 / 1.3	0.6 / 0.7 / 0.8 / 1.3	0.6 / 0.7 / 0.8 / 1.3	0.6 / 0.7 / 0.8 / 1.3	0.6 / 0.7 / 0.8 / 1.3
Line length	m	6.27	6.6	6.91	7.21	7.49
Line consumption	m	216	227	238	249	259
max. profile depth	m	2.49	2.6	2.72	2.84	2.95
min. profile depth	m	0.62	0.65	0.68	0.71	0.74
Weight	kg	3.4	3.7	4	4.3	4.6
Legal take-off weight	kg	60-80	70-90	80-100	90-110	100-130
take-off weight motor	kg
Places		1	1	1	1	1
Certification		B	B	B	B	B
