PHI SCALA (PAST MODEL)

SKU : PHI-SCALA-S-CC

Superseded by the Phi SCALA 2

SCALA, the revolutionary 2x2 liner by PHI. Semi light. Super performing. Climbing and racing are her strengths! She is a true beauty!

In the end PHI chose not to complete certification or start general production of the standard weight SCALA (1), instead they prioritised other projects over this (MAESTRO 2 / light, SOLA / GT, SONATA 2, VIOLA 2, SYMPHONIA 2 / light, TENOR 2 / light) and moved on to development of the SCALA 2 and SCALA 2 light, ready for the Red Bull X-alps 2023 race.

Product Details

Technical data (provisional)*

name		S	SM	ML	L	XL
size		18	19	20	21	23
certified weight range	kg	65-85	78-95	86-106	98-118	110-130
flat area	m²	20.56	22	23.45	24.93	26.39
projected area	m²	17.71	18.95	20.2	21.45	22.7
flat aspect ratio		6.77	6.77	6.77	6.77	6.77
projected aspect ratio		5.07	5.07	5.07	5.07	5.07
number of cells		78	78	78	78	78
projected span	m	9.48	9.8	10.12	10.43	10.72
flat span	m	11.8	12.2	12.6	13	13.37
line length	m	6.95	7.19	7.43	7.49	7.7
total line length	m	187	193	199	204	210
maximum chord	m	2.28	2.36	2.44	2.52	2.59
minimum chord	m	0.11	0.11	0.116	0.12	0.12
weight	kg	tbc	tbc	tbc	tbc	tbc
certification (EN/LTF)		*	*	*	*	*
riser length	mm	540	540	540	540	540
speedway	mm	165	180	180	180	180

Material: Porcher Skytex / Techfibre STA15

Risers: R09

* In the end PHI chose not to complete certification or start general production of the standard weight SCALA (1), instead they prioritised other projects over this (MAESTRO 2 / light, SOLA / GT, SONATA 2, VIOLA 2, SYMPHONIA 2 / light, TENOR 2 / light) and moved on to development of the SCALA 2 and SCALA 2 light, ready for the Red Bull X-alps 2023 race.
