Order info: The price is for wing only, rucksack and spreader bars are sold separately.
SORA - The Ultimate "Pro Tool"
The SORA is faultless in the critical phases of take-off and landing, and the handling will also bring joy to the pilot and comfort to the passenger.
In accordance with Sup’Air tradition, the choice of materials and construction methods ensures high durability and will guarantee many flying hours in total safety for the owner.
The wide certified weight range (from 120kg to 220kg) offers great versatility in all flight configurations whatever the conditions.
For optimal control, trimmers either accelerate or slow the glider down. They are fitted on a double strap and produce a softer sensation, in particular for the passenger, and to reduce the effort in pulling them down. They attach to the bottom of the riser with a magnet to stop them flapping in the wind.
The SORA is also fitted with brake tabs adjustable in height, so pilots of all sizes may fly it in total comfort.
Big ears stay in place thanks to a dedicated blocker, which is located facing the pilot for better control and safety. A new wingtip clean-up system will help remove stones and twigs from the glider more easily.
The positioning of rods reinforcing the profile has been especially designed in order to prevent friction on the upper surface thanks to a "buffer zone", in order to prevent early ageing and guarantee high durability.
- Size: 41m²
- Weight: 7500gr
Specifications
Piloting
- Qualified tandem pilots
- Foot- or tow-launch
Equipment
- Trimmers
- Ear blocker
- Adjustable brake tabs
- "Long life" Rods
- Wingtip clean-up system
Materials
- Upper surface cloth: Porcher Sport Skytex Universal 38 g/m²
- Inner surface cloth: Porcher Sport Skytex Universal 32 g/m²
- Supported ribs cloth: Porcher Sport Skytex Hard 40 g/m²
- Other ribs cloth: Porcher Sport Skytex Hard 32 g/m²
- Upper lines: Liros
- Lower lines: Edelrid
Certification
Made in Thailand
User's Manual
Download Sup'Air SORA User Manual (PDF)
Colours
- Earth (Blue-Green >> code 01)
- Wind (Blue-Purple >> code 02)
- Snow (Purple-Blue >> code 03)
- Flower (Purple-Green >> code 04)
- Grass
- Fire
Technical Details
Size (m²)
|
41
|
| Number of cells |
54 |
| Flat surface area (m²) |
41.2 |
| Span (m) |
14.9 |
| Chord (m) |
3.47 |
| Flat Aspect Ratio |
5.35 |
| Projected surface area (m²) |
35.1 |
| Projected span (m) |
11.7 |
| Projected aspect ratio |
3.9 |
| Glider weight (kg) |
7.5 |
| In-flight weight range (kg) |
120 – 220 |
| Trim speed (km/h) |
25 |
| Max. speed (km/h) |
52 |
| Certification |
EN- B EN 926-2 : 2005 & EN 926 -1 : 2006 /// LTF : 91/09 |
