Phi MAESTRO 2
Select all options to view stock availability

When in stock, UK approx 2-5 workdays, other countries see shipping page
Model Status: Current model
EN Certification: EN B
LTF Certification: LTF B
Technical data
Size | 19 | 21 | 22 | 23 | 25 |
---|---|---|---|---|---|
SWR¹
|
65-85 | 75-95 | 83-103 | 90-110 | 105-130 |
EWR²
|
85-90 | 95-100 | 103-108 | 110-115 | 130-135 |
CWR³
|
65-90 | 75-100 | 83-108 | 90-115 | 105-135 |
EWRM⁴ | 65-150 | 75-150 | 83-170 | 90-170 | 105-170 |
flat area m² | 21.86 | 24.15 | 25.35 | 26.45 | 28.72 |
projected area m²
|
18.82 | 20.81 | 21.81 | 22.77 | 24.72 |
flat aspect ratio
|
5.56 | 5.56 | 5.56 | 5.56 | 5.56 |
proj. aspect ratio
|
4.13 | 4.13 | 4.13 | 4.13 | 4.13 |
weight kg | 4.5 | 4.8 | 4.95 | 5.15 | 5.45 |
number of cells
|
76 | 76 | 76 | 76 | 76 |
projected span (m)
|
8.81 | 9.26 | 9.49 | 9.69 | 10.10 |
flat span (m)
|
11.02 | 11.59 | 11.87 | 12.12 | 12.63 |
line length (m)
|
6.55 | 6.89 | 7.06 | 7.21 | 7.51 |
maximum chord (m)
|
2.47 | 2.6 | 2.66 | 2.72 | 2.83 |
minimum chord (m)
|
0.56 | 0.59 | 0.6 | 0.62 | 0.64 |
riser length (mm)
|
600 | 600 | 600 | 600 | 600 |
speedway(mm)
|
180 | 180 | 180 | 180 | 200 |
certification (EN/LTF)
|
B | B | B | B | B |
certification DGAC
|
i.A. | i.A. | i.A. | i.A. | i.A. |
¹ Standard weight range in kilograms.
² Extended weight range in kilograms.
³ Certified weight range in kilograms.
⁴ Extended weight range motor, for powered flying, in kilograms.
i.A. = in process.
Colours
Standard colours: CC01 (Blue-Orange), CC02 (Orange-Black), CC03 (Purple-White) and CC04 (Bordeaux-Royal).
MAESTRO 2: the new benchmark!
It is not only the high complexity of this wing with its 76 cells and additional miniribs, offering an extremely smooth finish.
It's not only its breathtaking performance in thermaling, gliding and speed.
It's the balance. The handling and the feeling of being at one with this outstanding wing!
We love the very late stall point and long brake travel. The level of safety is even better than that of the original MAESTRO!
Designer's notes
"My personal feedback on flying the final MAESTRO 2 23 with 96kg (quite light with my light harness) in windy and turbulent conditions during our pre serial check:
I found the wing very confidence inspiring. The demand seems to be only a small step over the BEAT light. The canopy is very well defined and form stable. Handling is great. I think, this wing is for sure rising easiness, performance relation to a new higher level! Please try it yourself!"
- Hannes Papesh, Phi Designer
Materials
Porcher Skytex 32 / 27 doube coated
Risers
This wing is delivered with the "Semlight C Handle" R07 riser as standard (recommended).
You are free to customize and choose another riser free of charge but this will delay your order by 3-7 days.
If saving every gram is your top priority, you may choose the "Superlight" RZ3 riser. This reduces the weight on the tech data list by around 250-285g but compromises usability and increases speed system pressure.
Phi Promise Guarantee
All PHI wings are covered by the Phi Promise Guarantee. All damage repaired in the first year of use.
Product registration
Register your PHI product here.
Downloads
Condition | New |
---|---|
EN Certification | EN B |
LTF Certification | LTF B |
Other Certification | DGAC |
Shipping Details | When in stock, UK approx 2-5 workdays, other countries see shipping page |
Model Status | Current model |
