Good thing. Made. Better.
A class apart.
Our CHILIs are a class for themselves. The name CHILI has long since been symbol for the optimal synthesis between high performance and balance flying characteristics in the EN-B class. That’s why designing a new CHILI is probably the greatest challenge for our R&D team. The goal is to do more than just set a new milestone in the EN-B class. Our aim is to provide CHILI pilots with a glider that makes them feel like they have chosen the product with the highest comfort factor on the market.
"Next turnpoint: Out in the boondocks!" - Armin Harich, cross country ace
HOW DOES THE CHILI FLY?
Before we put pencil to paper, we spent a lot of time talking to the CHILI community. We asked thermal flyers, XC specialists, expert pilots, and our importers and dealers what they would like to see in the CHILI4. Their feedback became our mission:
The CHILI4 gives its pilots more precise feedback and can be steered more intuitively throughout the whole spectrum of its brake line travel than its predecessor, the CHILI3. Control line movement lies in ergonomically perfect space and the brake lines kick in promptly after a carefully selected delay. Brake travel and pressure are optimized to meet the requirements of thermal and XC pilots who love to spend hours exploring their favorite line. That’s why effective brake travel is a little shorter and the brake pressure a little higher than with the glider’s successful predecessor. The result is direct, precise and effortless handling.
A new canopy concept with a slightly higher cell count, decent shark nose and more attention to details in the cell construction and sail tension ensure constant internal pressure along the entire angle of attack area. The result is a glider that flies like on rails, even in turbulence conditions. We improved not only the glider’s performance along the entire polar curve – from off-bar cruising mode to near comp wing highspeed gliding – but also its stability in hands-off flying. The CHILI4 converts every updraft into altitude gain without rearing up in turbulence. This makes it even easier to core thermals than with its predecessor, making the CH4 the new the “climbing king” of the EN-B class.
To sum it up: We think CHILI pilots will love the “new one”. And the rest of the crowd will follow suit after the first test flight.
Our JET FLAPS extend the green arc as you approach the stall point, which substantially increases safety and also improves climb performance.
C-wires are nylon wires sewn into the glider over the anchor points of the C-level lines. Advantages: better load distribution, reduced drag, more performance.
Doubling the number of cells at the trailing edge increases its shape stability substantially. Advantage: fewer vortices improve the aerodynamics and with it the performance.
The Rigid Foil nylon wires on the leading edge help maintain its shape and ensure constant ram air pressure. Advantages: better takeoff behavior, more performance and lower canopy weight.
A precise calculation of the leading edge geometry and the installation of an additional strip of fabric reduce wrinkling in this sensitive part of the glider. Advantages: exact wing shape, more performance.
3 LINE LEVELS
The 3-line-level concept reduces the number of lines and the resulting drag. Advantages: more performance and a better overview at launch.
Together with a corresponding wing design, the shark nose technology improves pressure distribution in the canopy substantially. Advantages: much more solid flying feeling and substantial performance gain, especially when gliding on bar.
|Area flat (m²)||21,39||24,59||26,40||28,28||30,23|
|Area projected (m²)||18,34||21,08||22,64||24,25||25,92|
|Wingspan flat (m)||10,99||11,79||12,21||12,64||13,07|
|Wingspan projected (m)||8,79||9,43||9,77||10,11||10,45|
|Aspect ratio flat||5,65||5,65||5,65||5,65||5,65|
|Aspect ratio projected||4,21||4,21||4,21||4,21||4,21|
|Glider weight (kg)||4.9||5.2||5.5||5.8||6.1|
|Certified weight range (kg)||55-77||70-95||85-105||95-115||105-135|
|Upper sail||Porcher Skytex 40g|
|Lower sail||Porcher Skytex 40g|
|Ribs||Skytex 38g hard|
|Bands||Skytex 38g hard|
|Main lines||Liros PPSLS 180, Edelrid 9000-90|
|Middle lines||Edelrid 8000-90/ Edelrid 8000-50|
|Top lines||8000-50/ Liros|
|Brake lines||PPSL 160/Edelrid 8000-U130/Edelrid 8000-50/ Liros DC 35|
- CHILI4 XXS LTF/EN Flight test report
- CHILI4 XS LTF/EN Flight test report
- CHILI4 S LTF/EN Flight test report
- CHILI4 M LTF/EN Flight test report
- CHILI4 L LTF/EN Flight test report
Skywalk CHILI4 reviews
Your CHILI4 package
the high end intermediate CHILI4 comes with:
- 1x Glider backpack
- 1x Compression strap
- 1x Innerbag for glider
- 1x Riser bag
- 1x Manual
- 1x Bandana
- 1x Repair Kit
What are the glide ratio (L/D), trim and maximum speeds?
We know that these data are interesting for you as a pilot, but for us to publish them would be a bad idea for the following reasons:
1) Performance data are highly dependent on the drag of the pilot and are therefore related to sitting position and harness. The difference between aerodynamically favorable and unfavorable harnesses and sitting positions can be as much as a whole L/D number.
2) Performance increases with the size of the glider. A large glider will always outperform the same glider in a smaller size. So a question about the performance of a glider is always also a question about the size.
3) There is no normed method of testing the performance of paragliders. For example, speed varies with altitude and the associated different air pressure, but also with the total weight of the system.
That means that there simply isn’t THE speed or THE L/D that would allow a serious comparison with another glider. Performance data are dependent on the harness, the size of the glider, on the air mass and the total weight.
How do I calculate my takeoff weight?
Takeoff weight is calculated by adding the weight of the pilot including clothes to the weight of the equipment. The equipment consists of the harness, the reserve chute, the paraglider itself, and any flight instruments and other baggage you may carry (e.g. rucksack, etc.).
Is it OK for me to shorten the brake lines on my skywalk paraglider?
Changing the length of the brake lines can have a negative effect on the flying characteristics and extreme flight behavior. The paraglider needs a little more lead when flying on speed bar, otherwise the glider could be braked unintentionally, leading to a loss of performance. When performig extreme flying maneuvers, shortening the brake lines too much can cause complications during recovery from collapses, parachutal stall, etc.
Am I allowed to make modifications to my skywalk paraglider?
No, because the glider is certified the way it is delivered to you. Even the brake line length is part of the trim and must not be changed.
Why shall I not navigate my glider through the C-level
As opposed to gliders with two line levels with which you can change the angle of attack by pulling the rear risers, doing the same on a glider with three line levels causes the profile to deform. This results in a crease forming between levels, which makes the glider more susceptible to collapses. In an emergency, control deflections of several centimeters are possible.
Do the nylon wires in the glider near any special attention or packing method?
Our nylon wires are flexible and kink resistant, so they won’t break under normal circumstances. But due to the packing volume it is a good idea to lay the Rigid Foils in the leading on top of each other on both sides.
What are JetFlaps and how do they work?
Jet Flaps are a so-called split flap like those seen on a large airplane. When the glider is braked, the airflow is routed through the glider, restoring smooth airflow. This extends brake line travel and softens the stall behavior.
What advantage do the JetFlaps on my skywalk paraglider offer?
Lower flyable minimum airspeed. The speed range is wider and easier to control. The pilot has more time to react when flying near the stall point.
|EN Certification||EN B|
|LTF Certification||LTF B|
