Technical data
Size |
XS (18) |
S (20) |
M (22) |
ML (23) |
L (24) |
XL (26) |
| Number of cells | 56 | 56 | 56 | 56 | 56 | 56 |
| Projected span (m) | 8.29 | 8.74 | 9.18 | 9.4 | 9.61 | 10.02 |
| Projected area (m²) | 17.74 | 19.72 | 21.73 | 22.77 | 23.79 | 25.89 |
| Projected aspect ratio | 3.88 | 3.88 | 3.88 | 3.88 | 3.88 | 3.88 |
| Flat span (m) | 10.51 | 11.07 | 11.63 | 11.9 | 12.17 | 12.69 |
| Flat area (m²) | 20.8 | 23.11 | 25.48 | 26.7 | 27.9 | 30.37 |
| Flat aspect ratio | 5.31 | 5.31 | 5.31 | 5.31 | 5.31 | 5.31 |
| Line length (m) | 6.24 | 6.57 | 6.9 | 7.07 | 7.22 | 7.53 |
| Total line length (m) | 250 | 260 | 270 | 280 | 290 | 300 |
| Maximum chord (m) | 2.45 | 2.58 | 2.71 | 2.77 | 2.84 | 2.96 |
| Minimum chord (m) | 0.66 | 0.7 | 0.73 | 0.75 | 0.77 | 0.8 |
| Weight (kg) | 4.3 | 4.6 | 4.9 | 5.15 | 5.2 | 5.5 |
| Certified weight range (kg) | 50-75 | 65-85 | 75-95 | 83-103 | 90-110 | 105-130 |
| Certification (EN/LTF) | B | B | B | B | B | B |
| Material | Porcher Skytex 32 | |||||
| Risers | R06 (3+1) | |||||
| Riser length (mm) | 500 | 540 | 540 | 540 | 540 | 540 |
| Speedway (mm) | 150 | 150 | 180 | 180 | 180 | 200 |
Weight ranges
Colours
Standard colours: Blue-Black, Lime-Black, Gold-Black
Package
- Glider
- Inner bag
- Compression strap
- Backpack
The PHI rucksack is designed to be reduced and light, but still robust and convenient to carry. It can be packed very small, to minimize storage space in the harness.
BEAT of your heart!
At the request of many pilots, the BEAT has only robust, sheathed TECHNORA lines on the brakes and stabilo, which stand out clearly from the ground in their orange.
With this decision we follow our conviction that paragliding has to become easier again!
Despite the theoretically higher resistance of these somewhat thicker lines, we could not measure a performance disadvantage, on the contrary. Above all, this wing seems to benefit from its exceptionally clean finish.
The BEAT has a very high level of form stability due to its complex structure. This makes it fly extremely precise and gives excellent feedback!
Designer's note
Our test team immediately liked the first BEAT prototype extremely well. It was love at first sight! The handling is perfectly balanced, the performance is convincing and he also behaved very well in the maneuvers. Once again we had the right feeling and a little bit of luck!
So we are very happy to surprise the pilots with this wing! With the BEAT we are now able to offer 5 B wings (in addition to 4 wings in the A class). With our wide range, we want to make sure that every pilot finds the right wing for himself.
- Hannes Papesh
Technical features
With 56 cells and a flat aspect ratio of 5.3, the BEAT lines up between TENOR and MAESTRO. Technically it is a somewhat slimmed down MAESTRO with a few pinches of ALLEGRO (3 main lines), a little FANTASIA (intake) and of course SYMPHONIA (being extremely well balanced).
Reviews
To follow...
Additional Information
| Condition | New |
|---|---|
| EN Certification | EN B |
| LTF Certification | LTF B |
| Shipping Details | When in stock, UK approx 2-5 workdays, other countries see shipping page |
| Model Status | Current model |
